Samsung SSA-X100 Power Package for Control Panel Dubai



Samsung SSA-X100 Power Package for Control Panel Dubai

The Samsung SSA-X100 Power Package for Control Panel Dubai is an access control power package controller with the built-in power board so that you don’t need to prepare a separate DC 12V adapter for power supply.

Description

Samsung SSA-X100 Power Package for Control Panel



The Samsung SSA-X100 Power Package for Control Panel Dubai is an access control power package controller with the built-in power board so that you don’t need to prepare a separate DC 12V adapter for power supply. It has a controlled power provided for the internal access controller to guarantee steady operation, and features the backup battery against a power failure.

 The SSA-X100 by Samsung Dubai features an alarming function that warns the user of a power failure over the input port of the controller when AC power supply is disturbed. Attach the provided 4-pin cable to the 4-pin connector of the power board and plug in to the controller port so that it fits into AC and FAIL. For details on the I/O settings of the controller, refer to the SSA-X100 controller manual and SAMS S/W manual.

When the Samsung SSA-X100 controller ensures to be powered by the backup battery due to a power failure, the alert system will tell you of such an emergency to avoid a risk of discharged backup battery. Connect the provided 4-pin able to the 4-pin connector of the power board and plug it in to the controller port so that it fits into LOW and BATT.

Samsung SSA-X100 Power Package for Control Panel Features:

  • Power package for control panel (1 PSU)
  • Input : 90~250V AC, 50/60Hz, Max 1.2A
  • Output : 13.5V DC, 3.0A
  • Communication status via LED indicator
  • Surge protection (NFB)
  • Low battery check
  • AC power failure check
  • Battery recharge circuit
