Samsung SCP-2273HP Speed Dome Camera

The Samsung SCP-2273HP Speed Dome Camera Dubai is a high-resolution 680TV lines PTZ dome that hosts a powerful 27x optical zoom lens. The excellent 0.2/0.01Lux low light performance is further improved by Samsung’s SSNRIII noise reduction technology. Advanced features further improve the Samsung SCP-2273HP dome’s abilities such as; alarm schedules, privacy masks, highlight advantage and two control options RS-485 and the cable saving coaxial control.

The Samsung SCP-2273HP Dubai is x27 optical zoom PTZ Dome camera which is gives extraordinary video resolution of 680TV Lines at low light levels, down to 0.2 Lux in Color (0.01 Lux in Mono). With other features such as Samsung’s SSNRIII noise reduction, Highlight Compensation (HLC), true day/night (ICR) and more, the SCP-2273HP is powerful yet compact.

Samsung SCP-2273HP Speed Dome Camera Features:

• Fitted with 1/4 inch Sony 960H Ex-view HAD CCD II
• Supports High-Resolution Images of 680TVL in Colour & Mono
• Illumination 0.2Lux @F1.6, 0.0004Lux (Sens-up,x512) in Colour
• 01Lux @F1.6, 0.00002Lux (Sens-up,x512) in Mono
• Features 37x Optical Zoom (3.5 ~ 129.5mm) & 16x Digital Zoom
• True Day & Night (ICR), SSNRIII, Highlight Compensation
• Motion Detection, Privacy Masking & Alarm Inputs (x8) / Outputs (x3)
• Communication via Coaxitron or RS-485/422
• Supports Multiple Protocols – Pelco-C, Pelco-D/P, Samsung-T/E & more
• IP66 Housing with Fan & Heater
• Power Requirements – 24V AC 15W /60W (Fan & Heater On)
• Digital Flip function is useful to monitor moving objects or people passing directly under the camera; when an object or a person passes directly under the camera, its tilt motor follows the object or person over 90° to the other side of the tilt area without panning; screen inversion digitally adjusts and occurs at 90° or higher
• Smart P/T function automatically adjusts the control speed of the pan and tilt functions according to the current zoom ratio, enabling manual adjustment of functions for detailed controls when monitoring at high zoom ratios
• Camera Backup feature allows you to back up the camera’s sequence information and presets, which is useful when the camera or its install base are damaged or malfunctions occur
